2009 YU-SHINE VL-750/HR
Sold
2009 YU-SHINE VL-750/HR
Specifications
| Manufacturer | YU-SHINE |
| Model | VL-750/HR |
| Year | 2009 |
| Condition | Used |
| Max swing diameter | Ø 780 mm |
| Max turning diameter | Ø 750 |
| Max turning height | 650 mm |
| X axis travel | 480 mm |
| Z axis travel | 650 mm |
| Chuck diameter | Ø 530 mm |
| Spindle speed | 2.000 Rpm |
| Spindle nose | ASA A2-11 |
| Spindle motor power (cont/30 min) | 18,5/22 kW |
| Turret positions | 10 stations |
| Tools dimensions / boring bar diameter | 32x32 / Ø50 mm |
| Rapid feedrates X Axis | 20.000 mm/min |
| Rapid feedrates Z Axis | 20.000 mm/min |
| Accessories | Chip conveyor - Coolant tank with pumps - Various fix tool holders - Manuals - Electrical diagrams - EC CE Declaration |
